| Block Module |
| Dimensions (w x h) |
250mmx250mm |
Resolution (w x h) |
48 x 48 |
| Pixel pitch |
5.21mm |
Pixel Density |
36840 dots/㎡ |
| LED Configuration |
SMD3528 |
Pixel Configuration |
1R,1G,1B |
| Cabinet |
| Dimensions(w x h x d) (mm) |
500x500x60 |
Block Module Quantity |
4 |
| Physical Resolution (w x h) |
96 x 96 |
Physical Pixels (total) |
9216 |
| Weight (kgs) |
6,5 |
Material |
Aluminum |
| Average Power Comsumption (watt) |
250 |
Max Power (watts/sqm) |
750 |
| Parameter |
|
| Brightness |
1200 cd/㎡ |
| Viewing Angle |
140° |
| Minimum Viewing Distance |
4m |
| Brightness Control |
256 levels |
| Grey scale |
14bits (maximum) |
| Refresh frequency |
4800Hz (maximum) |
| Driving mode |
constant current driving |
| Driving IC |
LXY28161 |
| Scan method |
1/12 Scanning |
| Input power frequency |
50 or 60 Hz |
| Input Voltage |
86 ～ 264 Volt |
| Power adapter |
YHY |
| Blind spot rate |
＜1/10,000 |
| Lifetime at 50% brightness |
100,000 hours |
| International Protection |
IP43 |
| Operation temperature |
-20 ～﹢50 °C±10% |
| MTBF |
﹥10,000 hours |
| Color temperature |
6500K |
| Control distance |
Twisted pair network cable maximum transmission distance 130m.Multi-mode Optical fiber maximum 500m;Single-mode optical fiber maximum 10KM. |
| Signal input format |
Composite, S-Video, VGA, DVI, YPbPr, HDMI, SDI |
